I’ve created these examples to give you a better understanding of the design process and to showcase the range of services I offer.
Designing a modern air purifier for desk that can be manufactured by Injection molding and can clean air at a minimum rate of 5 ft3/min.
Designing a robotic arm featuring a claw mechanism and analyzing the power and torque requirements at each joint to support a maximum load of 10 kg.
This project involved the mechanical design of a soil reaper capable of penetrating 4–5 inches into the soil during operation, while offering a 12-inch ground clearance when the blade is retracted.Â
This project involves the creation of a high-quality 3D animated video showcasing the concept and functionality of a futuristic eVTOL (Electric Vertical Take-Off and Landing) taxi charging station.
This project focused on designing a helmet-shaped ashtray.The primary challenge was to accurately replicate the smooth, organic curves of a helmet, which was achieved using advanced surface modeling techniques in CAD software.
This project involved the design and development of two types of spunding valves—a vertical valve and a diaphragm-style valve—specially engineered for use in pressurized fermentation up to 30 PSI.
This project involved the conceptualization, 3D modeling, and creation of detailed engineering drawings for a modern bunk bed using SolidWorks.
This project focused on the design and development of a plenum box and accompanying panels for a dust collection system. The system was engineered for portability, ease of on-site assembly, and efficient airflow management.
In this project client needed engineering drawing to propose the idea to a company. I provided cad models, renders and engineering drawings for manufacturing, assembly and cutlist.
This project involved the complete design of a vehicle rooftop storage box built with a steel tube frame and sheet metal panels for durability, strength, and weather resistance.Â
Â
Here I have outlined my entire design process. Not all of these steps are necessary for every project, and your project may already be at a later stage. However, this will give you a general idea of what to expect when working with me.
Have a marketing idea or need to quickly get some high quality product design images?
I can do anything from simple images to complex animations of your SOLIDWORKS CAD designs that will help you clearly articulate your products look and feel to customers.
